The shaft-driven 4WD TT-02 chassis employs a longitudinal layout with the battery on the left and the motor on the right, to give excellent stability. In addition, it features identical left and right suspension arms and uprights for ease of assembly, plus easy-to-maintain gearboxes. It is a highly adaptable chassis, as it offers 2 different wheelbases, 2 ground clearance settings and 2 tread set-ups in addition to a range of 10 possible gear ratios. It is not short on looks either, with brake disc-shaped wheel hubs and stylish front bumper supports. Gun metal color 10-spoke wheels and slick tires make for a racy finish.
Specifications
- Ball Bearings
- Plastic Bushing
- Battery
- Sold Separately
- Body
- Polycarbonate
- Bushing Material
- Plastic
- Charger
- Sold Separately
- Chassis
- ABS Plastic
- Completion Level
- Kit
- Differential
- Gear Diffs
- Drive Type
- Forward/Brake/Reverse
- Drivetrain
- 4WD
- Gear Ratio
- Adjustable
- Motor Size
- 540
- Motor Type
- Brushed
- Product Height
- 4.92126" (125 mm)
- Product Length
- 18.3465" (466 mm)
- Product Width
- 7.40157" (188 mm)
- Radio
- Sold Separately
- Scale
- 1/10
- Servos
- Sold Separately
- Shock Type
- Friction Shocks
- Speed Control
- Included
- Suspension
- Fully Independent Double Wishbone
- Vehicle Type
- Touring Car
- Wheel Hex Size
- 12mm
- Wheelbase
- 10.1181" (257 mm)
